Product Name	Package	VRM (V)	IF(av) (A)	VF(V) @25℃ max.	@IF(A)	IR(uA) @25℃ max.	@VR(V)	IFSM(A) @8.3ms max.	TJ(℃)	Status
SBL8010	SBL	600	8	1.1	8	5	600	200	150	Active
SBL5010	SBL	1000	5	1.1	5	5	1000	160	150	Active
YBS3010	TMBF	1000	3	1.1	3	5	1000	95	150	Active
YBS4010	TMBF	1000	4	1.15	4	5	1000	125	150	Active
ABS6	ABS	600	1	1.1	1	5	400	35	150	Active
ABS8	ABS	800	1	1.1	1	5	800	35	150	Active
ABS10	ABS	1000	1	1.1	1	5	1000	35	150	Active
MB6S	MBS	600	1	1.1	1	5	600	30	150	Active
MB8S	MBS	800	1	1.1	1	5	800	30	150	Active
MB10S	MBS	1000	1	1.1	1	5	1000	30	150	Active
MB6F	MBF	600	1	1.1	1	5	600	30	150	Active
MB8F	MBF	800	1	1.1	1	5	800	30	150	Active
MB10F	MBF	1000	1	1.1	1	5	1000	30	150	Active
ABS206	ABS	600	2	1.1	2	5	600	60	150	Active
GBP306G	GBP	600	3	1.0	3	5	600	80	150	Active
GBP308G	GBP	800	3	1.0	3	5	800	80	150	Active
GBP310G	GBP	1000	3	1.0	3	5	1000	80	150	Active
KBP306G	KBP	600	3	1.0	3	5	600	80	150	Active
KBP308G	KBP	800	3	1.0	3	5	800	80	150	Active
KBP310G	KBP	1000	3	1.0	3	5	1000	80	150	Active
ABS208	ABS	800	2	1.1	2	5	800	60	150	Active
ABS210	ABS	1000	2	1.1	2	5	1000	60	150	Active
GBP206G	GBP	600	2	1.1	2	5	600	60	150	Active
GBP208G	GBP	800	2	1.1	2	5	800	60	150	Active
GBP210G	GBP	1000	2	1.1	2	5	1000	60	150	Active
KBP206G	KBP	600	2	1.1	2	5	600	60	150	Active
KBP208G	KBP	800	2	1.1	2	5	800	60	150	Active
KBP210G	KBP	1000	2	1.1	2	5	1000	60	150	Active
HBS8010	HBS	1000	8	0.9	8	5	1000	160	150	Active
ABS2	ABS	200	1	1.1	1	5	200	35	150	Active
ABS4	ABS	400	1	1.1	1	5	400	35	150	Active
ABS206N	ABS	1000	2	1.1	2	5	1000	55	150	Active
ABS202	ABS	200	2	1.1	2	10	200	60	150	Active
ABS204	ABS	400	2	1.1	2	10	400	60	150	Active
ABS210G	ABS	600	2	1.1	2	5	600	70	150	Active
UG2KB060	D3K	600	2	1	2	5	600	60	150	Active
UG2KB080	D3K	800	2	1	2	5	800	60	150	Active
UG2KB100	D3K	1000	2	1	2	5	1000	60	150	Active
UG3KB060	D3K	600	3	1.1	3	5	600	80	150	Active
UG3KB080	D3K	800	3	1.1	3	5	800	80	150	Active
UG3KB100	D3K	1000	3	1.1	3	5	1000	80	150	Active
UG4KB060	D3K	600	4	1.1	4	5	600	120	150	Active
UG4KB080	D3K	800	4	1.1	4	5	800	120	150	Active
UG4KB100	D3K	1000	4	1.1	4	5	1000	120	150	Active
UG6KB060	D3K	600	6	1.1	6	5	600	150	150	Active
UG6KB080	D3K	800	6	1.1	6	5	800	150	150	Active
UG6KB100	D3K	1000	6	1.1	6	5	1000	150	150	Active
UG8KB060	D3K	600	8	1	8	5	600	170	150	Active
UG8KB080	D3K	800	8	1	8	5	800	170	150	Active
UG8KB100	D3K	1000	8	1	8	5	1000	170	150	Active
GBU4J	GBU	1000	4	1	4	5	1000	150	150	Active
GBU606G	GBU	600	6	1.1	6	5	600	150	150	Active
GBU608G	GBU	800	6	1.1	6	5	800	150	150	Active
GBU610G	GBU	1000	6	1.1	6	5	1000	150	150	Active
GBU606	GBU	600	6	1.1	6	5	600	150	150	Active
GBU608	GBU	800	6	1.1	6	5	800	150	150	Active
GBU610	GBU	1000	6	1.1	6	5	1000	150	150	Active
GBU606L	GBU	600	6	1.1	6	5	600	150	150	Active
GBU608L	GBU	800	6	1.1	6	5	800	150	150	Active
GBU610L	GBU	1000	6	1.1	6	5	1000	150	150	Active
GBU806G	GBU	600	8	1	8	5	600	175	150	Active
GBU810G	GBU	1000	8	1	8	5	1000	175	150	Active
GBU806GL	GBU	600	8	0.95	8	5	600	200	150	Active
GBU1006G	GBU	600	10	1	10	5	600	200	150	Active
GBU1008G	GBU	800	10	1	10	5	800	200	150	Active
GBU1010G	GBU	1000	10	1	10	5	1000	200	150	Active
GBU1506G	GBU	600	15	1.3	15	5	600	260	150	Active
GBU1508G	GBU	800	15	1.3	15	5	800	260	150	Active
GBU1510G	GBU	1000	15	1.3	15	5	1000	260	150	Active
GBU1506L	GBU	600	15	0.93	15	1	600	260	150	Active
GBU2006	GBU	600	20	1	20	5	600	250	150	Active
GBU2008	GBU	800	20	1	20	5	800	250	150	Active
GBU2010	GBU	1000	20	1	20	5	1000	250	150	Active
GBU2506	GBU	600	25	1	25	5	600	1	150	Active
GBU2508	GBU	800	25	1	25	5	800	300	150	Active
GBU2510	GBU	1000	25	1	25	5	1000	300	150	Active
GBU3006	GBU	600	30	1	30	5	600	350	150	Active
GBU3008	GBU	800	30	1	30	5	800	350	150	Active
GBU3010	GBU	1000	30	1	30	5	1000	350	150	Active
GBU3506	GBU	600	35	1.05	35	5	600	400	150	Active
GBU3508	GBU	800	35	1.05	35	5	800	400	150	Active
GBU3510	GBU	1000	35	1.05	35	5	1000	400	150	Active
GBU3506L	GBU	600	35	1	35	5	600	400	150	Active
DB107	DB-S	1000	1	1	1	10	1000	50	150	Active
DB107S	GBU	1000	1	1	1	10	1000	50	150	Active
DB157S	DB-S	1000	1.5	1.1	1.5	5	1000	60	150	Active
DB207S	DB-S	1000	2	1.1	2	5	1000	60	150	Active
GBJ606G	GBJ	600	6	1	6	5	600	175	150	Active
GBJ608G	GBJ	800	6	1	6	5	800	175	150	Active
GBJ610G	GBJ	1000	6	1	6	5	1000	175	150	Active
GBJ2506G	GBJ	600	25	1.05	25	5	600	350	150	Active
GBJ2508G	GBJ	600	25	1.05	25	5	800	350	150	Active
GBJ2510G	GBJ	1000	25	1.05	25	5	1000	350	150	Active
GBJ5012	GBJ	1200	50	1.1	50	5	1200	1	150	Active
GBL406	GBL	1000	4	1.1	4	5	1000	135	150	Active
GBL408	GBL	1000	4	1.1	4	5	1000	135	150	Active
GBL410	GBL	1000	4	1.1	4	5	1000	135	150	Active
GBL606L	GBL	600	6	1.05	6	5	600	150	150	Active
GBL806L	GBL	600	8	1.05	8	5	600	200	150	Active
GBP306	GBP	600	3	1	3	5	600	60	150	Active
GBP308	GBP	800	3	1	3	5	800	60	150	Active
GBP310	GBP	1000	3	1	3	5	1000	60	150	Active
GBP410	GBP	1000	4	1.1	4	5	1000	80	150	Active
GBP406G	GBP	600	4	1.1	4	5	600	120	150	Active
GBP408G	GBP	800	4	1.1	4	5	800	120	150	Active
GBP410G	GBP	1000	4	1.1	4	5	1000	120	150	Active
GBP408L	GBP	800	4	1	4	5	800	130	150	Active
HBS6010	HBS	1000	6	1	6	5	1000	150	150	Active
TT8M	HBS	1000	8	1	8	5	1000	160	150	Active
KBJ406G	KBJ	600	4	1.1	4	10	600	135	150	Active
KBJ408G	KBJ	800	4	1.1	4	10	800	135	150	Active
KBJ410G	KBJ	1000	4	1.1	4	10	1000	135	150	Active
KBJ606L	KBJ	600	6	1.1	6	5	600	150	150	Active
KBJ608L	KBJ	800	6	1.1	6	5	800	150	150	Active
KBJ610L	KBJ	1000	6	1.1	6	5	1000	150	150	Active
KBJ606	KBJ	600	6	1.1	6	5	600	170	150	Active
KBJ608	KBJ	800	6	1.1	6	5	800	170	150	Active
KBJ610	KBJ	1000	6	1.1	6	5	1000	170	150	Active
KBJ806G	KBJ	600	8	1	8	10	600	175	150	Active
KBJ808G	KBJ	800	8	1	8	10	800	175	150	Active
KBJ810G	KBJ	1000	8	1	8	10	1000	175	150	Active
KBJ1506G	KBJ	600	15	1.1	15	5	600	220	150	Active
KBJ1508G	KBJ	800	15	1.1	15	5	800	220	150	Active
KBJ1510G	KBJ	1000	15	1.1	15	5	1000	220	150	Active
KBJ2510	KBJ	1000	25	1.1	25	5	1000	280	150	Active
KBJL15L	KBJL	600	15	1	15	5	600	240	150	Active
KBJL15K	KBJL	800	15	1	15	5	800	240	150	Active
KBJL15M	KBJL	1000	15	1	15	5	1000	240	150	Active
KBL406	KBL	600	4	1.1	4	5	600	130	150	Active
KBL408	KBL	800	4	1.1	4	5	800	130	150	Active
KBL410	KBL	1000	4	1.1	4	5	1000	130	150	Active
LDB10J	LDB-S	600	10	1	10	5	600	180	150	Active
LDB10K	LDB-S	800	10	1	10	5	800	180	150	Active
LDB10M	LDB-S	1000	10	1	10	5	1000	180	150	Active
LDB15J	LDB-S	600	15	1	15	5	600	250	150	Active
LDB15K	LDB-S	800	15	1	15	5	800	250	150	Active
LDB15M	LDB-S	1000	15	1	15	5	1000	250	150	Active
MG10F	MBF	1400	1	0.98	1	5	1400	28	150	Active
YBS3M	TMBF	1000	3	1.05	3	5	1000	95	150	Active
YBS8010	TMBF	1000	8	1.05	8	5	1000	160	150	Active
2W02	WOB	200	2	1.1	2	10	200	50	150	Active
2W04	WOB	400	2	1.1	2	10	400	50	150	Active
2W06	WOB	600	2	1.1	2	10	600	50	150	Active
2W08	WOB	800	2	1.1	2	10	800	50	150	Active
2W10	WOB	1000	2	1.1	2	10	1000	50	150	Active
HBS10M	HBS	1000	10	0.98	10	5	1000	180	150	Active
